IRL1004STRR
| Part No | IRL1004STRR |
|---|---|
| Manufacturer | Infineon Technologies |
| Description | MOSFET N-CH 40V 130A D2PAK |
| Lead Free Status / RoHS Status | Contains lead /RoHS non-compliant |
Specifications
Data sheet
| Drain to Source Voltage (Vdss): | 40V |
|---|---|
| Power Dissipation (Max): | 3.8W (Ta), 200W (Tc) |
| Package / Case: | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB |
| Mounting Type: | Surface Mount |
| Packaging: | Tape & Reel (TR) |
| Supplier Device Package: | D2PAK |
| Vgs(th) (Max) @ Id: | 1V @ 250µA |
| Drive Voltage (Max Rds On, Min Rds On): | 4.5V, 10V |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Detailed Description: | N-Channel 40V 130A (Tc) 3.8W (Ta), 200W (Tc) Surface Mount D2PAK |
| FET Feature: | - |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Email: | sale@wisdommobility.com |
| FET Type: | N-Channel |
| Series: | HEXFET® |
| Current - Continuous Drain (Id) @ 25°C: | 130A (Tc) |
| Input Capacitance (Ciss) (Max) @ Vds: | 5330pF @ 25V |
| Vgs (Max): | ±16V |
| Rds On (Max) @ Id, Vgs: | 6.5 mOhm @ 78A, 10V |
| Technology: | MOSFET (Metal Oxide) |
| Gate Charge (Qg) (Max) @ Vgs: | 100nC @ 4.5V |
| Operating Temperature: | -55°C ~ 175°C (TJ) |
Introduce
We can supply IRL1004STRR , send us a request quote to request IRL1004STRR pirce and lead time.Wisdom Mobility is a professional electronic components distributor. With 10+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IRL1004STRR.The price and lead time for IRL1004STRR depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part IRL1004STRR.We look forward to working with you to establish long-term relations of cooperation
