UPD166007T1F-E1-AY
| Part No | UPD166007T1F-E1-AY |
|---|---|
| Manufacturer | Renesas Electronics America |
| Description | High Side Power Switch 5-Pin(4+Tab) TO-252 T/R |
| Lead Free Status / RoHS Status | Lead Free / RoHS compliant |
| Availability:12628 pcs | |||||
| Quantity | Unit Price | Ext. Price | |||
|---|---|---|---|---|---|
| 1+ | $0.7754 | $78 | |||
| 10+ | $0.7599 | $380 | |||
| 100+ | $0.7366 | $737 | |||
| 1000+ | $0.7133 | $713 | |||
| 10000+ | $0.6823 | $682 | |||
| The above prices does not include taxes and freight rates, which will be calculated on the order pages. | |||||
Specifications
Data sheet
| Output Type | N-Channel |
|---|---|
| Mount | Surface Mount |
| Output Configuration | High Side |
| Driver Number of Bits | 1 |
| Feature | Auto Restart |
| Terminal Finish | Matte Tin (Sn) |
| Radiation Hardening | No |
| Height Seated (Max) | 2.4mm |
| Number of Functions | 1 |
| Terminal Position | SINGLE |
| Package / Case | TO-252-5, DPak (4 Leads + Tab), TO-252AD |
| Turn Off Time | 700 µs |
| JESD-30 Code | R-XSSO-G5 |
| Turn On Time | 400 µs |
| Terminal Form | GULL WING |
| Number of Terminations | 5 |
| Supply Voltage | 12V |
| Built-in Protections | TRANSIENT; OVER CURRENT; THERMAL |
| ECCN Code | EAR99 |
| Lead Free | Lead Free |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Input Type | Non-Inverting |
| Supply Voltage-Min (Vsup) | 8V |
| Switch Type | General Purpose |
| Voltage - Load | 8V~18V |
| Ratio - Input:Output | 1:1 |
| Mounting Type | Surface Mount |
| Rds On (Typ) | 8m Ω |
| JESD-609 Code | e3 |
| Factory Lead Time | 16 Weeks |
| Pin Count | 5 |
| Number of Outputs | 1 |
| Fault Protection | Current Limiting (Fixed), Over Temperature |
| Output Current Flow Direction | SOURCE SINK |
| Length | 6.5mm |
| Subcategory | Peripheral Drivers |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Published | 2008 |
| Interface | On/Off |
| Max Output Current | 30A |
