PDTC115EK,115
| Part No | PDTC115EK,115 |
|---|---|
| Manufacturer | NXP Semiconductors. |
| Description | TRANS PREBIAS NPN 250MW SMT3 |
| Lead Free Status / RoHS Status | Lead Free / RoHS compliant |
Specifications
Data sheet
| DC Current Gain (hFE) (Min) @ Ic, Vce: | 80 @ 5mA, 5V |
|---|---|
| Package / Case: | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type: | Surface Mount |
| Packaging: | Tape & Reel (TR) |
| Supplier Device Package: | SMT3; MPAK |
| Resistor - Emitter Base (R2): | 100 kOhms |
| Current - Collector (Ic) (Max): | 20mA |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Detailed Description: | Pre-Biased Bipolar Transistor (BJT) NPN - Pre-Biased 50V 20mA 250mW Surface Mount SMT3; MPAK |
| Resistor - Base (R1): | 100 kOhms |
| Voltage - Collector Emitter Breakdown (Max): | 50V |
| Power - Max: | 250mW |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Email: | sale@wisdommobility.com |
| Vce Saturation (Max) @ Ib, Ic: | 150mV @ 250µA, 5mA |
| Series: | - |
| Base Part Number: | PDTC115 |
| Other Names: | 934057288115 PDTC115EK T/R PDTC115EK T/R-ND |
| Transistor Type: | NPN - Pre-Biased |
| Current - Collector Cutoff (Max): | 1µA |
Introduce
We can supply PDTC115EK,115 , send us a request quote to request PDTC115EK,115 pirce and lead time.Wisdom Mobility is a professional electronic components distributor. With 10+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PDTC115EK,115.The price and lead time for PDTC115EK,115 depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part PDTC115EK,115.We look forward to working with you to establish long-term relations of cooperation
